Support services for the
consulting engineer.
A working partner from schematic design to bid documents. We translate factory engineering into field-ready answers, so you can hold your line on the spec.
- Application Depth
- High Temperature Exhaust Systems
- Layout Deliverables
- 2D CAD & 3D BIM / Revit
- Design Output
- Complete Submittal Packages
- Documentation
- Factory-Certified Back Pressure Sizing
- Spec Compliance
- 100% CSI Division 23 Ready
Six deliverables, every project.
Fan Selection and Vent Sizing
Rigorous CFM, static pressure, fan curve and mechanical draft calculations, delivered with clear, factory-backed cut sheets ready for your design schedule.
CSI Specification
Ready-to-paste Section 23 51 00, 23 31 13 and 23 38 13 master specifications, written as either manufacturer-neutral or basis-of-design to match your firm's standards.
Code Compliant
Direct verification against NFPA 96, IMC, UMC and UL listings (103 / 1738 / 1978 / 2221) with explicit code edition references cited to simplify AHJ reviews.
Constructability Review
Detailed pre-drawing audits of roof penetrations, plenum clearances and structural support points to eliminate field conflicts before plans go out to bid.
Site Walks
On-site field surveys to evaluate existing conditions, identify retrofit constraints and align with local inspectors early, so the design works in the real world.
Submittal Stewardship
A complete, bid-ready package including factory drawings, cut sheets and back pressure calculations, delivered in five business days to keep construction moving.
We bring 30+ years of exhaust design to your office.
Our team comes to you and trains your engineering group directly: high-temperature venting, listed grease duct, mechanical draft and heat recovery, taught from three decades of real project experience. Your engineers walk out better equipped for their next design review, and better prepared for the AHJ.
Schedule a Lunch & LearnFormat
60 minutes at your office, up to 25 people, lunch provided. AIA-style handout included.
Curriculum
Grease duct listings, UL 1738 category II and IV venting, mechanical draft control, heat recovery.
Hands-On
Cutaway duct sections, damper assemblies and termination hardware on the table.
Follow-Up
Spec language, listing letters and sizing examples emailed the same day.
Reviewing a project right now?
Send the program and any existing schematics. We'll come back with sizing, listings, and spec language within five business days.
